P-SERIES

10+ Years Experience in 2000kW-3600kWDiesel Engine Manufacturing.
20+ Years Experience in Over 300kW DieselEngine Manufacturing.
30+ Years Experience in the Diesel Engine &Generator Set Field.
Inventing the World's First V-type 14-Cylinder, 16-Cylinder, and 20-Cylinder Engines with Cylinder Diameters of 128-132-135mm.
Reliable
Low Emissions
Low Fuel Consumption
Low Maintenance Costs

Model OUTPUT	PTAA6L-EG490	PTAA8V-EG575	PTAA10V-EG690
Standby Power(LTP) [kW]	490	575	690
Prime Power(PRP) [kW]	450	515	630
Continuous Power(COP)[kW]	331	359	446
Engine Speed [rpm]		1500
GENERAL DATA
Type of Cylinders	On-Line	V-Type	V-Type
No. of Cylinders	6	8	10
Intake Method	Turbocharged & Air-Air Intercooled
Fuel Consumption @ Standby Power [g/kWh]	204.2	201.3	202.8
Injection Type	High Pressure Common Rail
Displacement [L]	14.3	16.6	20.8
Dimensions (WxHxL)[m]	1.00x1.26x1.72	1 .41x1.40x1.34	1.41x1.40x1.72
Weight [kg]	1025	1125	1425
Start Mode	Motor Starter
Speed Governing System	Electronic Governing

Model OUTPUT	PTAA12V-EG815	PTAA16V-EG980	PTAA16V-EG1120
Standby Power(LTP) [kW]	815	980	1120
Prime Power(PRP) [kW]	730	890	1010
Continuous Power(COP)[kW]	543	672	706
Engine Speed [rpm]		1500
GENERAL DATA
Type of Cylinders	V-Type	V-Type	V-Type
No. of Cylinders	12	16	16
Intake Method	Turbocharged & Air-Air Intercooled
Fuel Consumption @ Standby Power [g/kWh]	200.8	204.1	197.5
Injection Type	High Pressure Common Rail
Displacement [L]	24.9	31.7	33.2
Dimensions (WxHxL)[m]	1.41x1.43x1.91	1.10x1.43x2.19	1.10x1.43x2.19
Weight [kg]	1625	2250	2250
Start Mode	Motor Starter
Speed Governing System	Electronic Governing

　　The data in this document will be updated continuously due to the technological development of our company.If users need the latest technical information,please contact our company or our cooperating agents and OEM companies to obtain it.The data in this document does not serve as any legal certificate of the contract text.Our company has the right to change and interpret these data without any notice.

Version: 28-12
