Q-SERIES

10+ Years Experience in 2000kW-3600kWDiesel Engine Manufacturing.
20+ Years Experience in Over 300kW DieselEngine Manufacturing.
30+ Years Experience in the Diesel Engine &Generator Set Field.
Inventing the World's First V-type 14-Cylinder, 16-Cylinder, and 20-Cylinder Engines with Cylinder Diameters of 128-132-135mm.
Reliable
Low Emissions
Low Fuel Consumption
Low Maintenance Costs

Model OUTPUT	QTA8V-EG1230D	QTA10V-EG1670D	QTA12V-EG1960D	QTA16V-EG2220D	QTA16V-EG2440D
Standby Power(LTP) [kW]	1230	1670	1960	2220	2440
Prime Power(PRP) [kW]	1120	1529	1780	2000	2220
Continuous Power(COP)[kW]	990.37	1111.37	1567.13	1777.9	1857.53
Engine Speed [rpm]	1500
GENERAL DATA
Type of Cylinders	V-Type
No. of Cylinders	8	10	12	16	16
Intake Method	Turbocharged & Air-Air Intercooled
Fuel Consumption @ Standby Power [g/kWh]	196.54	197.34	193.37	188.26	196.49
Injection Type	High Pressure Common Rail
Displacement [L]	14.3	53.8	64.5	86	86
Dimensions (WxHxL)[m]	1.46x1.82x2.60	2.60x3.00x5.05	1.46x1.82x3.10	1.46x1.82x3.60	1.46x1.82x3.60
Weight [kg]	3600	4200	5000	6200	6200
Start Mode	Motor Starter
Speed Governing System	Electronic Governing

Model OUTPUT	QTA20V-EG2660D	QTA20V-EG2950D	QTA20V-EG3100D	OTA20V-EG3200D	OTA20V-EG3330D
Standby Power(LTP) [kW]	2660	2950	3100	3200	3330
Prime Power(PRP) [kW]	2440	2680	2810	2900	3010
Continuous Power(COP)[kW]	1916.33	2296.45	2306.45	2316.45	2326.45
Engine Speed [rpm]	1500
GENERAL DATA
Type of Cylinders	V-Type
No. of Cylinders	16	20	20	20	20
Intake Method	Turbocharged & Air-Air Intercooled
Fuel Consumption @ Standby Power [g/kWh]	192.87	193.05	193.03	193.03	193.03
Injection Type	High Pressure Common Rail
Displacement [L]	86	107.5	107.5	107.5	107.5
Dimensions (WxHxL)[m]	1.46x1.82x3.60	1.46x1.82x4.11	146x1.82x4.11	1.46x1.82x4.11	1.46x1.82x4.11
Weight [kg]	6200	7200	7200	7200	7200
Start Mode	Motor Starter
Speed Governing System	Electronic Governing

　　The data in this document will be updated continuously due to the technological development of our company.If users need the latest technical information,please contact our company or our cooperating agents and OEM companies to obtain it.The data in this document does not serve as any legal certificate of the contract text.Our company has the right to change and interpret these data without any notice.

Version: 28-12
