F-Series 400v

10+ Years Experience in 2000kW-3600kWDiesel Engine Manufacturing.
20+ Years Experience in Over 300kW DieselEngine Manufacturing.
30+ Years Experience in the Diesel Engine &Generator Set Field.
Inventing the World's First V-type 14-Cylinder, 16-Cylinder, and 20-Cylinder Engines with Cylinder Diameters of 128-132-135mm.
Reliable
Low Emissions
Low Fuel Consumption
Low Maintenance Costs

Model OUTPUT	FPG550E-40A	FPG688E-40A	FPG775E-40A	FPG880E-40A
Voltage [V]	400
Rated Current[A]	722	902	1010	1155
Standby Power(TP)[kVA]	550	688	775	880
Standby Power(LTP) [kW]	440	550	620	704
Prime Power(PRP) [kVA]	500	625	700	800
Prime Power(PRP) [kW]	400	500	560	640
Continuous Power(COP)[kVA]	375	440	500	625
Continuous Power(COP)[kW]	300	352	400	500
GENERAL DATA
Phase	3
Power Factor	0.8
Maximum Altitude Requirement[m]	1000
Fuel Consumption @ Standby Power [g/kWh]	204.2	200.2	202.8	200.8
Frequency[Hz]	50
Dimensions (WxHxL)[m]	1.15x1.60x3.30	1.45x2.10x3.20	1.45x2.10x3.30	1.80x2.15x3.70
Weight [kg]	3370
Ingress Projection	IP23

Model OUTPUT	FPG1100E-40A	FPG1250E-40A	FPG1400E-40A	FPG1875E-40A
Voltage [V]	400
Rated Current[A]	1443	1624	1804	2435
Standby Power(TP)[kVA]	1100	1250	1400	1875
Standby Power(LTP) [kW]	880	1000	1100	1500
Prime Power(PRP) [kVA]	1000	1125	1250	1688
Prime Power(PRP) [kW]	800	900	1000	1350
Continuous Power(COP)[kVA]	750	800	1125	1265
Continuous Power(COP)[kW]	600	640	900	1012
GENERAL DATA
Phase	3
Power Factor	0.8
Maximum Altitude Requirement [m]	1000
Fuel Consumption @ Standby Power [g/kWh]	204.1	197.5	196.54	197.5
Frequency[Hz]	50
Dimensions (WxHxL)[m]	2.14x2.24x4.15	2.1 4x2.34x4.45	2.20x2.55x4.70	2.20x3.00x5.05
Weight [kg]	6600	6750	7350	11000
Ingress Projection	IP23

　　The data in this document will be updated continuously due to the technological development of our company.If users need the latest technical information,please contact our company or our cooperating agents and OEM companies to obtain it.The data in this document does not serve as any legal certificate of the contract text.Our company has the right to change and interpret these data without any notice.

Version: 28-12
